Scissor Components
126 GS
™
-30m • 32m • 30 • 32 • 46 • 55 Part No. 1309020GT
9-9
Scissor Assembly - GS-4046
How to Disassemble the Scissor
Assembly
Bodily injury hazard. This
procedure requires specific repair
skills, lifting equipment and a
suitable workshop. Attempting
this procedure without these
skills and tools could result in
death or serious injury and
significant
component damage.
Dealer service is strongly
recommended.
Note: When removing a hose assembly or fitting,
the O-ring (if equipped) on the fitting and/or hose
end must be replaced. All connections must be
torqued to specification during installation. Refer to
Specifications, Hydraulic Hose and Fitting Torque
Specifications.
Note: After replacing the scissor assembly, the
platform overload system must be calibrated.
Refer to Repair Procedure, How to Calibrate the
Platform Overload System.
1 Turn the key switch to ground controls and
pull out the red Emergency Stop button to the
on position at both ground and platform
controls.
2 Raise the platform 7 to 9 feet / 2,1 to 2,8 m.
3 Lift the safety arm, move it to the center of the
scissor arm and rotate down to a vertical
position.
4 Lower the platform onto the safety arm.
Crushing haz
ard. Keep hands
clear of the safety arm when
lowering the platform.
5 At the ground controls, turn the key switch to
the off position and push in the red
Emergency Stop button to the off position.
6 Disconnect the battery pack from the
machine.
Electrocution/burn hazard.
Contact with electrically charged
circuits could result in death or
serious injury. Remove all rings,
watches and other jewelry.
7 Remove the fasteners securing the large
platform height sensor cover to the large
platform height sensor bracket.
8 Remove the platform height sensor cover.
9 Tag and disconnect the platform height
sensor from the platform height sensor
harness.
10 Remove the fastener securing the platform
height sensor assembly to the number 1 inner
arm.
11 Remove the platform height sensor assembly
from the number 1 pivot pin.
12 Remove the plastic nut securing the squeeze
connector to the large platform height sensor
bracket.
