Service and Repair Manual August 2021
Hydraulic Symbols Legend
214 GS
â„¢
-30m • 32m • 30 • 32 • 46 • 55 Part No. 1309020GT
Hydraulic cylinder Variable speed motor Pressure transducer
Solenoid operated
2 position 4 way
directional valve
Relief valve Bi-directional motor Solenoid operated
2 position 2 way
blocking valve
normally open
Solenoid operated
2 position 4 way
directional valve
Priority flow regulator Brake
Solenoid operated
2 position 2 way valve
normally closed
Proportional solenoid operated
2 position 2 way directional valve
normally closed
Accumulator Check valve Solenoid operated
2 position 2 way
directional valve
normally closed
Solenoid operated
3 position 5 way
directional valve
Fixed displacement
pump
Shuttle valve Solenoid operated 3 position
4 way directional valve
Solenoid operated 3 position
4 way directional valve
Filter Orifice with size
