August 2021 Service and Repair Manual
Specifications
Part No. 1309020GT GS
™
-30m • 32m • 30 • 32 • 46 • 55 5
Function speed, maximum from platform controls
(with 1 person in platform)
Models with electric drive
Platform down
34 to 41 s
-2646, GS-2646 XH
Platform up
Platform down
37 to 43 s
26 to 34 s
Platform down
53 to 61 seconds
26 to 34 seconds
-4046
Platform up
Platform down
62 to 72 s
39 to 48 s
Platform up
Platform down
91 to 95 s
56 to 60 s
-3232 Outrigger leveling capacity, maximum
Hydraulic Oil Specifications
Hydraulic Fluid Specifications
Genie specifications require hydraulic oils which are
designed to give maximum protection to
hydraulic
systems, have the ability to perform over a wide
temperature range, and the viscosity index should
exceed 140. They should provide excellent antiwear,
oxidation prevention, corrosion inhibition, seal
conditioning, and foam and aeration suppressio
n
Cleanliness level,
minimum
250 p
Recommended Hydraulic Fluid
Optional Hydraulic Fluids
Shell
Tellus S2 V 32
Shell Tellus S2 V 46
Shell Tellus S4 VX 32
Shell Donax TG (Dexron III)
Chevron 5606A
Petro Canada Environ MV
UCON Hydrolube HP-
Note: Genie specifications require additional
equipment and special installation instructions for
the approved optional fluids. Consult Genie
Product Support before use.
Optional fluids may not have
the same hydraulic lifespan and
may result in component
damage.
Note: Extended machine operation can cause the
hydraulic fluid temperature to increase beyond its
maximum allowable range. If the hydraulic fluid
temperature consistently exceeds 200°F / 90°C an
optional oil cooler may be required.
