August 2021 Service and Repair Manual
Scissor Components
Part No. 1309020GT GS
â„¢
-30m • 32m • 30 • 32 • 46 • 55 125
Steer End
Non-steer End
1 - Number 7 pivot pin 13 - Number 2 center pivot pin (Qty. 2) 25 - Number 4 outer arm
2 - Number 6 center pivot pin (Qty. 2) 14 - Number 2 pivot pin (steer end) 26 - Number 4 pivot pin (non-steer end)
3 - Number 6 pivot pin (steer end) 15 - Number 1 center pivot pin (Qty. 2) 27 - Upper lift cylinder barrel-end pivot pin
4 - Number 5 center pivot pin 16 - Number 1 inner arm 28 - Number 3 inner arm
5 - Upper lift cylinder rod-end pivot pin
17 - Number 1 pivot pin (steer end) (Qty.
2)
29 - Number 3 pivot pin (non-steer end)
6 - Number 5 pivot pin (steer end) 18 - Number 6 inner arm 30 - Number 2 inner arm
7 - Number 4 center pivot pin (Qty. 2) 19 - Number 6 outer arm 31 - Number 2 inner arm
8 - Number 4 pivot pin (steer end) 20 - Number 6 pivot pin (non-steer end) 32 - Number 2 pivot pin (non-steer end)
9 - Number 3 outer arm 21 - Number 5 inner arm 33 - Lower lift cylinder barrel-end pivot pin
10 - Number 3 center pivot pin (Qty. 2) 22 - Number 5 outer arm 34 - Number 1 outer arm
11 - Lower lift cylinder rod-end pivot pin 23 - Number 5 pivot pin (non-steer end)
12 - Number 3 pivot pin (steer end) 24 - Number 4 inner arm
