Service and Repair Manual August 2021
Scissor Components
124 GS
™
-30m • 32m • 30 • 32 • 46 • 55 Part No. 1309020GT
113 Lower the arm to the stowed position.
Bodily injury hazard. Keep
hands clear of moving parts
when lowering the scissor arms.
114 Secure the ends of the scissor arms together
at the steer end of the machine with a strap or
other suitable device.
115 Secure the ends of the scissor arms together
at the non-steer end of the machine with a
strap or other suitable device.
116 Remove the retaining fasteners securing the
chassis mount bracket to the chassis.
117 Remove the linkset from the machine.
Bodily injury hazard. The
number
1 inner and outer arms
4 and #29) may
become unbalanced and fall if
not properly
supported when
removed from the machine.
Component damage hazard. Be
sure not to damage the limit
switch or level sensor
components when the number
1
inner and outer arms (index
4 and #29) are removed from
To Next Page
