Terex Genie GS-1330m User Manual

August 2021 Service and Repair Manual
Scissor Components
Part No. 1309020GT GS
™
-30m • 32m • 30 • 32 • 46 • 55 123
98 Use a soft metal drift to remove the number
2 pivot pin (index #12) from the steer end of
the machine. Remove the number 2 inner arm
(index #25) from the machine.
Crushing hazard. T
he number
2
inner arm (index #25) may
become unbalanced and fall if
not properly supported when the
pivot pin is removed.
99 Attach a lifting strap from an overhead
supporting device to the number 1 inner arm
(index #14).
100 Raise the number 1 inner arm (index #14)
approximately 2 feet / 60 cm.
101 Place a 4 x 4 x 48 inch / 10 cm x 10 cm x
1.2 m long block across both sides of the
chassis under the number 1 center pivot pin
(index #13).
102 Lower the scissor arms onto the block that
was placed across the chassis.
Bodily injury hazard. Keep
hands clear of moving parts
when lowering the scissor arms.
103 Attach a lifting strap from an overhead
supporting device to the lug of the rod end of
the lower lift cylinder.
104 Tag, disconnect and plug the hydraulic hose
on the lower lift cylinder. Cap the fittings on
the cylinder.
Bodily injury hazard. Spraying
hydraulic oil can penetrate and
burn skin. Loosen hydraulic
connections very slowly to allow
t
he oil pressure to dissipate
gradually. Do not allow oil to
squirt or spray.
105 Tag and disconnect the wire harness from
the solenoid valve on the cylinder.
106 Tag and disconnect the wire harness from
the platform overload pressure transducer.
107 Raise the lift cylinder to a vertical position.
108 Remove the pin retaining fasteners from the
lift cylinder barrel-end pin (index #28). Use a
soft metal drift to remove the pin. Remove the
lift cylinder from the machine.
Crushing hazard. The lift
cylinder will fall
if not properly
supported when the pivot pin is
removed.
Component damage hazard. Be
careful not to damage the valve
or fittings on the cylinder while
removing it from the machine.
109 Remove the cables from the number 1 cable
bridge and lay them off to the side.
Component damage hazard.
Cables can be damaged if they
are kinked or pinched.
110 Disconnect the number 1 cable bridge from
the number 1 outer arm (index #29) and
remove the cable bridge from the machine.
111 Attach a lifting strap from an overhead
supporting device to the number 1 inner arm
(index #14).
112 Raise the arm slightly and remove the block.
