Service and Repair Manual August 2021
Scissor Components
96 GS
™
-30m • 32m • 30 • 32 • 46 • 55 Part No. 1309020GT
60 Attach a lifting strap from an overhead
supporting device to the number 2 outer arm
(index #19) at the battery pack side.
61 Remove the external snap rings and retaining
fasteners from the number 2 center pivot pin
(index #7) at the battery pack side.
62 Use a soft metal drift to remove the number
2 center pivot pin (index #7) at the battery
pack side.
Bodily injury hazard. The
number
2 outer arm at the
battery pack side may become
unbalanced and fall if not
properly supported when
removed from the machine.
63 Use a soft metal drift to tap the number
2 pivot pin (index #20) in the other direction at
the non-steer end. Remove the number
2 outer arm (index #19) from the battery pack
side of the machine.
Bodily injury hazard. The
number
2 outer arm at the
battery pack side may become
unbalanced and fall if not
properly supported when
removed from the machine
.
64 Remove the number 3 pivot pin (index #17)
from the non-steer end of the machine.
65 Attach a lifting strap from an overhead
supporting device to the number 2 inner arm
(index #18).
66 Remove the retaining fasteners from the
number 2 pivot pin (index #8) at the steer end
of the machine.
67 Use a soft metal drift to remove the number
2 pivot pin (index #8). Remove the number
2 inner arm (index #18) from the machine.
Bodily injury hazard. The
number
2 inner arm may
become unbalanced and fall if
not properly suppo
rted when
removed from the machine.
68 Remove the safety arm from the number
2 inner arm (index #18) that was just
removed.
69 Attach a lifting strap from an overhead
supporting device to the number 1 inner arm
(index #10).
70 Raise the number 1 inner arm (index #10)
approximately 2 feet / 60 cm and install the
safety arm between the number 1 inner arm
(index #10) and the number 1 outer arm
(index #22) at the non-steer end of the
machine. Lower the scissor arms onto the
safety arm.
Bodily injury hazard. Keep
hands clear of moving parts
when lowering the scissor arms
onto the safety arm.
71 Attach a lifting strap from an overhead
supporting device to the lug on the rod end of
the lift cylinder (index #5). Raise the lift
cylinder approximately 3 ft / 1 m.
72 Tag, disconnect and plug the hydraulic hoses
on the lift cylinder. Cap the fittings on the
cylinder.
Bodily injury hazard.
Spraying
hydraulic oil can penetrate and
burn skin. Loosen hydraulic
connections very slowly to allow
the oil pressure to dissipate
gradually. Do not allow oil to
squirt or spray.
