August 2021 Service and Repair Manual
Scissor Components
Part No. 1309020GT GS
â„¢
-30m • 32m • 30 • 32 • 46 • 55 101
22 Remove the pivot pins securing the number
2 arm assembly to the scissor stack. Remove
the arm assembly.
23 Tag, disconnect and plug the hydraulic hoses
from the lift cylinder. Cap the fittings on the
cylinder.
Bodily injury hazard. Spraying
hydraulic oil can penetrate and
burn skin. Loosen hydraulic
connections very slowly to allow
the oil pressure to dissipate
gradually. Do not allow oil to
squirt or spray.
24 Remove the cables from the lift cylinder and
number 1 inner arm.
25 Remove the fasteners securing the platform
height sensor cover to the chassis.
26 Remove the platform height sensor cover.
27 Tag and disconnect the platform height
sensor from the platform height sensor
harness.
28 Remove the fasteners securing the platform
height sensor short arm cover to the number
1 inner arm.
29 Remove the fasteners securing the platform
height sensor to the chassis. Remove the
sensor.
30 Support the number 1 inner and outer arms
and lift cylinder with an overhead supporting
device.
31 Remove the pivot pins securing the number
1 arm assembly to the chassis and slider
blocks. Remove the arm assembly with the lift
cylinder.
