Service and Repair Manual August 2021
Scissor Components
128 GS
â„¢
-30m • 32m • 30 • 32 • 46 • 55 Part No. 1309020GT
24 Remove the platform. Refer to Repair
Procedure, How to Remove the Platform.
25 Remove the cables from cable bridges a, b, c,
d and e.
26 Remove the retaining fasteners from the
number 7 pivot pin (index #1).
27 Use a soft metal drift to remove the number
7 pivot pin (index #1). Remove the platform
mount bracket from the machine.
28 Attach a lifting strap from an overhead
supporting device to the number 6 outer arm
at the ground control side (index #19).
29 Remove the retaining fasteners from the
number 6 center pivot pin (index #2) at the
ground control side.
30 Place a rod through the number 6 center pivot
pin at the ground control side (index #2) and
twist to remove the pin.
31 Remove the retaining fasteners from the
number 6 pivot pin (index #20) at the non-
steer end.
32 Use a soft metal drift to remove the number
6 pivot pin (index #20) from the non-steer end
of the machine. Remove the number 6 outer
arm at the ground control side (index #19)
from the machine.
Crushing hazard. The number
6
o
uter arm at the ground control
side (index #19) may become
unbalanced and fall if not
properly supported when
removed from the machine.
33 Attach a lifting strap from an overhead
supporting device to the number 6 outer arm
at the battery side (index #19).
34 Remove the retaining fasteners from the
number 6 center pivot pin (index #2) at the
battery side.
35 Place a rod through the number 6 center pivot
pin at the battery side (index #2) and twist to
remove the pin.
36 Remove the number 6 outer arm (index #19)
from the machine.
Crushing hazard. The number
6
outer arm (index #19) may
become unbalanced and fall if
not properly supported when
removed f
rom the machine.
37 Attach a lifting strap from an overhead
supporting device to the number 6 inner arm
(index #18). Raise the arm to a vertical
position.
38 Remove the retaining fasteners from the
number 6 pivot pin at the steer end of the
machine (index #3).
39 Use a soft metal drift to remove the number
6 pivot pin (index #3) from the steer end of the
machine. Remove the number 6 inner arm
(index #18) from the machine.
Crushing hazard. The number
5
inner arm (index #16) may
become unbalanced and fall if
not pr
operly supported when
removed from the machine.
40 Tag, disconnect and plug the hydraulic hose
on the upper lift cylinder. Cap the fittings on
the cylinder.
Bodily injury hazard. Spraying
hydraulic oil can penetrate and
burn skin. Loosen hydraulic
connecti
ons very slowly to allow
the oil pressure to dissipate
gradually. Do not allow oil to
squirt or spray.
41 Attach a lifting strap from an overhead
supporting device to the number 5 outer arm
at the ground control side (index #22).
