Terex Genie GS-1330m User Manual

Service and Repair Manual August 2021
Scissor Components
130 GS
™
-30m • 32m • 30 • 32 • 46 • 55 Part No. 1309020GT
61 Remove the number 4 outer arm (index #25)
from the machine.
Crushing hazard. The number
4
outer arm (index #25) may
become unbalanced and fall if
not properly supported when
removed from the machine.
62 Attach a lifting strap from an overhead
supporting device to the number 4 inner arm
(index #24). Raise the arm to a vertical
position.
63 Remove the retaining fasteners from the
number 4 pivot pin at the steer end of the
machine (index #8).
64 Use a soft metal drift to remove the number
4 pivot pin (index #8) from the steer end of the
machine. Remove the number 4 inner arm
(index #24) from the machine.
Crushing hazard. The number
4
inner arm (index #24) may
become unbalanced and fall if
not properly supported when
removed from the machine.
65 Remove the cables from cable bridges f,h,i,j,k
and l.
Componen
t damage hazard.
Cables can be damaged if they
are kinked or pinched.
66 Attach a lifting strap from an overhead
supporting device to the number 3 outer arm
at the ground control side (index #9).
67 Remove the retaining fasteners from the
number 3 center pivot pin (index #10) at the
ground control side.
68 Place a rod through the number 3 center pivot
pin at the ground control side (index #10) and
twist to remove the pin.
69 Remove the retaining fasteners from the
number 3 pivot pin (index #29) at the non-
steer end.
70 Use a soft metal drift to remove the number
3 pivot pin (index #29) from the non-steer end
of the machine. Remove the number 3 outer
arm at the ground control side (index #9) from
the machine.
Crushing hazard. The number
3
o
uter arm at the ground control
side (index #9) may become
unbalanced and fall if not
properly supported when
removed from the machine.
71 Attach a lifting strap from an overhead
supporting device to the number 3 outer arm
at the battery side (index #9).
72 Remove the number 3 outer arm (index #9)
from the machine.
Crushing hazard. The number
3
outer arm (index #9) may
become unbalanced and fall if
not properly supported when
removed from the machine.
73 Attach a lifting strap from an overhead crane
to the number 3 inner arm (index #28). Raise
the number 3 inner arm and place a 4 x 4 x
48 inch / 10 cm x 10 cm x 1.2 m block across
the link stack to gain access to the barrel end
pivot pin (index 27).
74 Attach a lifting strap from an overhead
supporting device to the lug of the rod end of
the upper lift cylinder.
75 Raise the lift cylinder to a vertical position.
Crushing h
azard. The lift
cylinder will fall if not properly
supported when the pivot pin is
removed.
Component damage hazard. Be
careful not to damage the valve
or fittings on the cylinder while
removing it from the machine.
76 Use a soft metal drift to remove the upper lift
cylinder barrel end pivot pin (index #27) from
the machine.
