Service and Repair Manual August 2021
Scissor Components
136 GS
â„¢
-30m • 32m • 30 • 32 • 46 • 55 Part No. 1309020GT
16 Install the fasteners removed in 14 to the
number 1 inner arm pivot bracket and
chassis.
Tip
-over hazard. Failure
to install the fasteners securing
the number
1 inner arm pivot
bracket to the chassis, could
result in the machine tipping
over, causing death or serious
injury.
17 Connect the battery pack to the machine.
18 Turn the key switch to ground controls.
19 Press and hold the ground control scroll up
and scroll down buttons.
20 Pull out the red Emergency Stop button to the
on position at the ground controls.
21 Using the ground control menu buttons,
navigate to Service Override Mode. Select
Service Override Mode.
Note: The machine must be in Service Override
Mode to raise the platform. While in Service
Override Mode, only the GCON will operate with
limited functionality. The platform will raise a
predetermined amount of time and stop.
22 Raise the platform and rotate the safety arm
to the stowed position.
23 Fully lower the platform to the stowed
position.
24 Remove the platform. Refer to Repair
Procedure, How to Remove the Platform.
25 Remove the retaining fasteners that attach
the ladder to the drive chassis. Remove the
ladder and set aside.
26 Remove the cables from the linkage
assembly.
27 Remove the platform. Refer to Repair
Procedure, How to Remove the Platform.
28 Remove the retaining fasteners that attach
the ladder to the drive chassis. Remove the
ladder and set aside.
29 Remove the cables from the linkage
assembly.
Component damage hazard.
Cables and hoses can be
damaged if they are kinked or
pinched.
30 Using an overhead supporting device attach a
4 hook sling chain to the ends of the number
6 inner arm. Make the chains tight but do not
apply lifting pressure.
31 Remove the retaining fasteners from the
number 6 pivot pins.
Note: Do not remove the external snap ring.
32 Using a soft metal drift, remove the pivot pins
and set aside.
33 Carefully lift the linkage assembly off of the
machine and place it on a structure capable of
supporting it.
34 Using a suitable supporting device, attach a
strap to the rod end of the upper lift cylinder.
Do not apply pressure.
35 Remove the upper cylinder rod end pivot pin
retaining fasteners.
36 Using a soft metal drift, remove the pivot pin.
37 Lower the lift cylinder and remove the strap.
