Terex Genie GS-1330m User Manual

August 2021 Service and Repair Manual
Specifications
Part No. 1309020GT GS
™
-30m • 32m • 30 • 32 • 46 • 55 3
Fluid capacities
Hydraulic tank
GS
-1330m, GS-1432m, GS-1932m,
GS
-1932m Lite, GS-1932m XH
1.06 g
allons
4 l
iters
Hydraulic system (including tank)
GS
-1330m, GS-1432m, GS-1932m,
GS
-1932m Lite, GS-1932m XH
1.5 g
allons
5,68 l
iters
Hydraulic tank
Models with hydraulic drive
GS
-1530, GS-1532, GS-1930, GS-
1932, GS
-1932 XH
3.4 g
allons
12,9 l
iters
Hydraulic tank
Models with electric drive
GS
-1530, GS-1532, GS-1930, GS-
1932, GS
-1932 XH
1.0 g
allons
3,8 l
iters
Hydraulic system (including tank)
Models with hydraulic drive
GS
-1530, GS-1532, GS-1930, GS-
1932, GS
-1932 XH
3.8 gallons
14,2 liters
Hydraulic system (including tank)
Models with electric drive
GS
-1530, GS-1532, GS-1930, GS-
1932, GS
-1932 XH
1.46 gallons
5,5 liters
Hydraulic tank
Models with hydraulic drive
GS
-2032, GS-2632
3.4 g
allons
12,9 l
iters
Hydraulic tank
Models with electric drive
GS
-2032, GS-2632, GS-3232, GS-
2046, GS
-2646, GS-2646 XH, GS-3246,
GS
-3246 XH
4.0 g
allons
15,1 l
iters
Hydraulic system (including tank)
Models with hydraulic drive
GS
-2032, GS-2632
4.5 g
allons
17 l
iters
Hydraulic system (including tank)
Models with electric drive
GS
-2032, GS-2632, GS-3232, GS-
2046, GS
-2646, GS-2646 XH, GS-3246,
GS
-3246 XH
6.13 g
allons
23,2 l
iters
Hydraulic tank
GS
-4046
4.9 gallons
18,5 liters
Hydraulic system
(including tank)
GS
-4046
7.84 gallons
29,7 liters
Hydraulic tank
GS
-4655
5.9 gallons
22,4 liters
Hydraulic system (including tank) GS
-
4655
7.94 g
allons
30 l
iters
Tires and wheels
GS
-1330m, GS-1432m, GS-1932m, GS-1932m Lite,
GS-1932m XH
Tire size (solid rubber)
10 x 3 i
n
25,4 x 7,6 cm
Tire contact area
6.5 s
q in
42 cm
2
Castle nut torque, dry
200 ft-
lbs
271,2 Nm
Castle nut torque, lubricated
150 ft-
lbs
203,4 Nm
GS-1530, GS-1532, GS-1930, GS-1932, GS-1932 XH
Tire size (solid rubber)
12 x 4.5
in
30,5 x 11,4
cm
Tire contact area
9 s
q in
58 cm
2
Castle nut torque, dry
300 ft-
lbs
406,7 Nm
Castle nut torque, lubricated
225 ft-
lbs
305 Nm
GS
-2032, GS-2632
Models with hydraulic drive
Tire size (solid rubber)
15 x 5 i
n
38,1 x 12,7 cm
Tire
contact area
17.22 s
q in
117 cm
2
Castle nut torque, dry
300 ft-
lbs
406,7 Nm
Castle nut torque, lubricated
225 ft-
lbs
305 Nm
GS
-2032, GS-2632, GS-3232, GS-2046, GS-2646, GS-
2646 XH, GS
-3246, GS-3246 XH, GS-4046, GS-4655
Models with electric drive
Tire size (solid rubber)
15 x 5 i
n
38,1 x 12,7 cm
Tire contact area
17.22 s
q in
117 cm
2
Hex head cap screw, dry
90 ft-
lbs
122 Nm
Hex head cap screw, lubricated
80 ft-
lbs
108,5 Nm
