August 2021 Service and Repair Manual
Scissor Components
Part No. 1309020GT GS
â„¢
-30m • 32m • 30 • 32 • 46 • 55 159
Full Load Calibration: Part 1
1 Fully charge the batteries and check the
hydraulic fluid level.
Note: The hydraulic fluid level must be between
the FULL and ADD marks on the hydraulic tank.
2 Apply a thin layer of dry film lubricant to the
area of the chassis where the scissor arm
wear pads make contact.
3 Chock both sides of the wheels at the steer
end of the machine.
4 Place the maximum rated load in the platform.
Secure the load to the platform.
-1330m, GS-1432m, GS-1930,
-1932, GS-1932 XH, GS-1932m,
-1932m Lite, GS-1932m XH, GS-
-3232
500 lbs / 227 k
-1530, GS-1532
600 lbs / 272 k
-2032
800 lbs / 363 k
frequent nuisance trips
occurring after calibrating a GS
-3232 m
achine, it is
recommended to recalibrate the machine, full load
and no load, with 25
0 kg of weight in the platform.
1200 lbs / 544 k
-2646, GS-2646 XH
1000 lbs / 454 k
-3246, GS-3246 XH
700 lbs / 317 k
-4046, GS-4655
5 Turn the key switch to ground controls.
6 At the ground controls, press and hold the
Menu Up and Menu Down buttons.
7 While pressing both buttons down, pull out the
red Emergency Stop Button.
8 Release the Menu Up and Menu Down
buttons after the ground controller powers up.
9 Press the Menu Up or Menu Down buttons to
scroll to, Select Option. Press the Enter
button.
10 Press the Menu Up or Menu Down buttons to
scroll to Platform Overload. Press the Enter
button.
11 Press the Menu Up or Menu Down buttons to
scroll to Platform Overload Calibrate. Press
the Enter button.
12 Confirm the Platform Overload Calibrate
selection by pressing the Enter button again.
13 Press the Menu Up or Menu Down buttons to
select Full Load calibration. Press the Enter
button.
14 Press the Enter button to confirm rated load is
in the platform.
15 At the ground controls, press and hold the
Function Enable and Platform Up buttons until
the platform reaches maximum height.
16 GS-4046: Press and hold the Menu Enter
button to determine the maximum height. The
machine will lower for 1.2 seconds and then
raise in 1.2 second durations, until maximum
height is reached. When the platform reaches
the maximum height, a message will appear
on the LCD screen to release the Menu Enter
button.
Note: Do not release the Menu Enter button
before the message appears on the LCD
screen.
All other models: When the platform reaches
maximum height, press the ground controls
Enter button. Allow the ground controls to
gather data.
