Service and Repair Manual August 2021
Scissor Components
162 GS
â„¢
-30m • 32m • 30 • 32 • 46 • 55 Part No. 1309020GT
No Load Calibration
30 Fully charge the batteries and check the
hydraulic fluid level.
Note: The hydraulic fluid level must be between
the FULL and ADD marks on the hydraulic tank.
31 Apply a thin layer of dry film lubricant to the
area of the chassis where the scissor arm
wear pads make contact.
32 Chock both sides of the wheels at the steer
end of the machine.
33 Turn the key switch to ground controls.
34 At the ground controls, press and hold the
Menu Up and Menu Down buttons.
35 While pressing both buttons down, pull out the
red Emergency Stop Button.
36 Release the Menu Up and Menu Down
buttons after the ground controller powers up.
37 Press the Menu Up or Menu Down buttons to
scroll to, Select Option. Press the Enter
button.
38 Press the Menu Up or Menu Down buttons to
scroll to Platform Overload. Press the Enter
button.
39 Press the Menu Up or Menu Down buttons to
scroll to Platform Overload Calibrate. Press
the Enter button.
40 Confirm the Platform Overload Calibrate
selection by pressing the Enter button again.
41 Press the Menu Up or Menu Down buttons to
select No Load calibration. Press the Enter
button.
42 Press the Enter button to confirm no load is in
the platform.
43 At the ground controls, press and hold the
Function Enable and Platform Up buttons until
the platform reaches maximum height.
44 GS-4046: Press and hold the Menu Enter
button to determine the maximum height. The
machine will lower for 1.2 seconds and then
raise in 1.2 second durations, until maximum
height is reached. When the platform reaches
the maximum height, a message will appear
on the LCD screen to release the Menu Enter
button.
Note: Do not release the Menu Enter button
before the message appears on the LCD
screen.
All other models: When the platform reaches
maximum height, press the ground controls
Enter button. Allow the ground controls to
gather data.
45 When prompted, press and hold the Function
Enable and Platform Down buttons. The
platform will lower, then automatically stop at
a predetermined point to gather data. Allow
the ground controls to gather data.
46 Continue pressing the Function Enable and
Platform Down buttons throughout the
lowering and data gathering sequence. The
machine will stop to gather data and lower
several times before the machine reaches the
stowed position. When the platform reaches
the stowed position. Press the enter button.
Note: GS-2032, GS-2646, GS-2646 XH, GS-
4046 models, continue to step 49.
Note: All other models, continue with step 47.
