Terex Genie GS-1330m User Manual

August 2021 Service and Repair Manual
Type "HXXX" Faults
Part No. 1309020GT GS
™
-30m • 32m • 30 • 32 • 46 • 55 189
Type "HXXX" Faults, (continued)
DTC
Number
Message on
GCON LCD
Description Possible Causes Failure Mode
H106:
H106:COILFAULT
DECK EXTEND:BAT-
Short circuit of the platform extend
circuit to battery negative.
• Short circuit in PED harness.
• PED extend valve coil short circuit.
• GCON ECM.
All functions inhibited.
H107:
H107:COILFAULT
DECK EXTEND:OPEN
Open circuit in the platform extend
circuit.
• Open circuit in PED harness.
• PED extend valve coil open circuit.
• GCON ECM.
All functions inhibited.
H108:
H108:COILFAULT
DECK EXTEND:BAT+
Short circuit of the platform extend
circuit to battery positive.
• Short circuit in PED harness.
• PED extend valve coil short circuit.
• GCON ECM.
All functions inhibited.
H109:
H109:COILFAULT
DECK RETRACT:BAT-
Short circuit of the platform retract
circuit to battery negative.
• Short circuit in PED harness.
• PED retract valve coil short circuit.
• GCON ECM.
All functions inhibited.
H110:
H110:COILFAULT
DECK RETRACT:OPEN
Open circuit in the platform retract
circuit.
• Open circuit in PED harness.
• PED retract valve coil open circuit.
• GCON ECM.
All functions inhibited.
H111:
H111:COILFAULT
DECK RETRACT:BAT+
Short circuit of the platform retract
circuit to battery positive.
• Short circuit in PED harness.
• PED retract valve coil short circuit.
• GCON ECM.
All functions inhibited.
H114:
H114:COILFAULT
DECK ENABLE:BAT+
Short circuit of the platform enable
circuit to battery positive.
• Short circuit in PED harness.
• PED enable valve coil short circuit.
• GCON ECM.
All functions inhibited.
H115:
H115:COILFAULT
DECK ENABLE
Short circuit of the platform enable
circuit.
• Short circuit in PED harness.
• GCON ECM.
All functions inhibited.
