August 2021 Service and Repair Manual
Electrical Component and Wire Color Legends
Part No. 1309020GT GS
â„¢
-30m • 32m • 30 • 32 • 46 • 55 209
Electrical Component Legend, continued
Item
Description
JC9 Joystick
K1 Contactor
KS1 Key switch
LS
Limit switch
LS1 = Maximum drive height (GS-3232)
LS6 = Platform down
LS7 = Pothole
LS8 = Pothole
LS10 = Maximum drive height (GS-3232)
M5 Hydraulic power unit
N.C. Normally closed
N.C.H.O Normally closed held open
N.O.H.C. Normally open held closed
P
Emergency power switch
P1 = Emergency Stop button, GCON
P2 = Emergency Stop button, PCON
PT Pressure transducer
PT1 = Left front outrigger (GS-3232)
PT2 = Right front outrigger (GS-3232)
PT3 = Left rear outrigger (GS-3232)
PT4 = Right rear outrigger (GS-3232)
PT15 = Platform Overload
R30 Resistor
S Sensor
S7 = Level sensor
S8 = Outrigger level sensor (GS-3232)
S14 = Platform height sensor
U Electronic component
U3 = Printed circuit board, PCON
U5 = ECM - Electronic Control Module
U6 = Motor controller
U9 = Battery charger
U13 = Inverter (if equipped)
Y Valve coil
Y1 = Parallel (GS-32, GS-46)
Y2 = Lift pressure selector (GS-4046)
Y3 = Steer right
Y4 = Steer left
Y5 = Drive reverse
Y6 = Drive forward
Y7 = Platform down
Y8 = Platform up
Y9 = Platform down (GS-3232, GS-3246)
Y33 = Left rear outrigger (GS-3232)
Y34 = Right rear outrigger (GS-3232)
Y35 = Left front outrigger (GS-3232)
Y36 = Right front outrigger (GS-3232)
Y39 = Outrigger retract (GS-3232)
Y40 = Outrigger extend (GS-3232)
WIRE COLOR LEGEND
Color
Description
BK Black
BK/RD Black/Red
BL Blue
BL/BK Blue/Black
BL/OR Blue/Orange
BL/WH Blue/White
BR Brown
GR Green
GR/BK Green/Black
GR/WH Green/White
GR/YL Green/Yellow
LB Light Blue
OR Orange
OR/BK Orange/Black
OR/RD Orange/Red
OR/WH Orange/White
RD Red
RD/BK Red/Black
RD/WH Red/White
WH White
WH/BK White/Black
YL Yellow
