Service and Repair Manual August 2021
Hydraulic Tank
44 GS
â„¢
-30m • 32m • 30 • 32 • 46 • 55 Part No. 1309020GT
Models with hydraulic drive
Note: Includes GS-4655 electric drive.
1 Disconnect the battery pack from the
machine.
Electrocution/burn hazard.
Contact with electrically charged
circuits could result in death or
serious injury. Remove all rings,
watches and other
jewelry.
Tag and disconnect the hydraulic tank return hard
line from the filter. Remove the hard line from the
machine. Cap the fitting on the filter head.
2 Tag and disconnect the hydraulic tank hard
line from the pump. Remove the hard line
from the machine. Cap the fitting on the
pump.
3 Remove the hydraulic tank retaining fasteners
and remove the hydraulic tank from the
machine.
Bodily injury hazard. Spraying
hydraulic oil can penetrate and
burn skin. Loosen hydraulic
connections very slowly to allow
the oil pressure to dissipate
gradually. Do not allow oil to
squirt or spray.
Remove the hydraulic tank cap and drain the tank
into a suitable container.
Hydraulic retaining fasteners, dry
35 in-
retaining fasteners, lubricated
26 in-
