Service and Repair Manual August 2021
Scissor Components
82 GS
™
-30m • 32m • 30 • 32 • 46 • 55 Part No. 1309020GT
Steer End Non-steer End
1 - Number 3 pivot pin (steer end) 10 - Number 1 inner arm
2 - Number 3 center pivot pin (Qty. 2) 11 - Lower lift cylinder rod-end pivot pin
3 - Number 3 outer arm
12 - Number 2 pivot pin (non-steer end)
4 - Number 2 pivot pin (steer end)
13 - Number 2 inner arm
5 - Number 2 center pivot pin (Qty. 2)
14 - Number 2 outer arm
6 - Number 1 pivot pin (steer end)
15 - Number 1 pivot pin (non-steer end)
7 - Lift cylinder barrel-end pivot pin
16 - Number 1 inner arm
8 - Number 1 center pivot pin (Qty. 2)
17 - platform height sensor
9 - Number 1 outer arm
18 - Number 1 pivot pin
