LMK04821
,
LMK04826
,
LMK04828
www.ti.com
SNAS605AR –MARCH 2013–REVISED DECEMBER 2015
9.7.1.4 ID_PROD[15:8], ID_PROD
These registers contain the product identifier. This is a read only register.
Table 12. ID_PROD Register Configuration, ID_PROD[15:0]
MSB LSB
0x004[7:0] 0x005[7:0]
POR
BIT REGISTERS FIELD NAME DESCRIPTION
DEFAULT
7:0 0x004 ID_PROD[15:8] 208 MSB of the product identifier.
7:0 0x005 ID_PROD 91 LSB of the product identifier.
9.7.1.5 ID_MASKREV
This register contains the IC version identifier. This is a read only register.
Table 13. Register 0x006
POR
BIT NAME DESCRIPTION
DEFAULT
36 IC version identifier for LMK04821
7:0 ID_MASKREV 37 IC version identifier for LMK04826
32 IC version identifier for LMK04828
9.7.1.6 ID_VNDR[15:8], ID_VNDR
These registers contain the vendor identifier. This is a read only register.
Table 14. ID_VNDR Register Configuration, ID_VNDR[15:0]
MSB LSB
0x00C[7:0] 0x00D[7:0]
Table 15. Registers 0x00C, 0x00D
BIT REGISTERS NAME POR
DESCRIPTION
DEFAULT
7:0 0x00C ID_VNDR[15:8] 81 MSB of the vendor identifier.
7:0 0x00D ID_VNDR 4 LSB of the vendor identifier.
Copyright © 2013–2015, Texas Instruments Incorporated Submit Documentation Feedback 55
Product Folder Links: LMK04821 LMK04826 LMK04828
