9.7.2.5 SDCLKoutY_ADLY_EN, SDCLKoutY_ADLY
These registers set the analog delay parameters for the SYSREF outputs.
Table 20. Registers 0x105, 0x10D, 0x115, 0x11D, 0x125, 0x12D, 0x135
BIT NAME POR
DESCRIPTION
DEFAULT
7:5 NA 0 Reserved
Enables analog delay for the SYSREF output.
SDCLKoutY
4 0 0: Disabled
_ADLY_EN
1: Enabled
Sets the analog delay value for the SYSREF output. Selecting analog delay adds an
additional 700 ps in propagation delay. Effective range is 700 ps to 2950 ps.
Field Value Delay Value
0 (0x0) 0 ps
1 (0x1) 600 ps
SDCLKoutY
3:0 0
_ADLY 2 (0x2) 750 ps (+150 ps from 0x1)
3 (0x3) 900 ps (+150 ps from 0x2)
... ...
14 (0xE) 2100 ps (+150 ps from 0xD)
15 (0xF) 2250 ps (+150 ps from 0xE)
