TMS320F2810, TMS320F2811, TMS320F2812
TMS320C2810, TMS320C2811, TMS320C2812
SPRS174T –APRIL 2001–REVISED MAY 2012 www.ti.com
8 Mechanical Data
Table 8-1 through Table 8-4 provide the thermal resistance characteristics for the various packages.
Table 8-1. Thermal Resistance Characteristics for 179-Ball GHH
PARAMETER 179-GHH PACKAGE UNIT
Psi
JT
0.658 °C/W
Θ
JA
42.57 °C/W
Θ
JC
16.08 °C/W
Table 8-2. Thermal Resistance Characteristics for 179-Ball ZHH
PARAMETER 179-ZHH PACKAGE UNIT
Psi
JT
0.658 °C/W
Θ
JA
42.57 °C/W
Θ
JC
16.08 °C/W
Table 8-3. Thermal Resistance Characteristics for 176-Pin PGF
PARAMETER 176-PGF PACKAGE UNIT
Psi
JT
0.247 °C/W
Θ
JA
41.88 °C/W
Θ
JC
9.73 °C/W
Table 8-4. Thermal Resistance Characteristics for 128-Pin PBK
PARAMETER 128-PBK PACKAGE UNIT
Psi
JT
0.271 °C/W
Θ
JA
41.65 °C/W
Θ
JC
10.76 °C/W
The following mechanical package diagram(s) reflect the most current released mechanical data available
for the designated device(s).
