0
100
200
300
400
500
600
0 20 40 60 80 100 120 140 160
Total Power
SYSCLKOUT (MHz)
Power (mW)
0
50
100
150
200
250
0 20 40 60 80 100 120 140 160
SYSCLKOUT (MHz)
Current (mA)
IDD IDDIO IDDA
Total 3.3-V current
TMS320F2810, TMS320F2811, TMS320F2812
TMS320C2810, TMS320C2811, TMS320C2812
SPRS174T –APRIL 2001–REVISED MAY 2012 www.ti.com
A. Test conditions are as defined in Table 6-2 for operational currents.
B. I
DD
represents the total current drawn from the 1.8-V rail (V
DD
). It includes a small amount of current (<1 mA) drawn
by V
DD1
.
C. I
DDA
represents the current drawn by V
DDA1
and V
DDA2
rails.
D. Total 3.3-V current is the sum of I
DDIO
and I
DDA
. It includes a small amount of current (<1 mA) drawn by V
DDAIO
.
Figure 6-3. C2812/C2811/C2810 Typical Current Consumption Over Frequency
Figure 6-4. C2812/C2811/C2810 Typical Power Consumption Over Frequency
96 Electrical Specifications Copyright © 2001–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320F2810 TMS320F2811 TMS320F2812 TMS320C2810 TMS320C2811 TMS320C2812
