The PLL, clocking, watchdog and low-power modes, are controlled by the registers listed in Table 3-15.
Table 3-15. PLL, Clocking, Watchdog, and Low-Power Mode Registers
(1)
NAME ADDRESS SIZE (x16) DESCRIPTION
Reserved 0x00 7010 – 0x00 7017 8
Reserved 0x00 7018 1
Reserved 0x00 7019 1
High-Speed Peripheral Clock Prescaler Register for
HISPCP 0x00 701A 1
HSPCLK clock
Low-Speed Peripheral Clock Prescaler Register for
LOSPCP 0x00 701B 1
LSPCLK clock
PCLKCR 0x00 701C 1 Peripheral Clock Control Register
Reserved 0x00 701D 1
LPMCR0 0x00 701E 1 Low-Power Mode Control Register 0
LPMCR1 0x00 701F 1 Low-Power Mode Control Register 1
Reserved 0x00 7020 1
PLLCR 0x00 7021 1 PLL Control Register
(2)
SCSR 0x00 7022 1 System Control and Status Register
WDCNTR 0x00 7023 1 Watchdog Counter Register
Reserved 0x00 7024 1
WDKEY 0x00 7025 1 Watchdog Reset Key Register
Reserved 0x00 7026 – 0x00 7028 3
WDCR 0x00 7029 1 Watchdog Control Register
Reserved 0x00 702A – 0x00 702F 6
(1) All of the above registers can only be accessed by executing the EALLOW instruction.
(2) The PLL control register (PLLCR) is reset to a known state by the XRS signal only. Emulation reset (through Code Composer Studio)
will not reset PLLCR.
