TMS320F2810, TMS320F2811, TMS320F2812
TMS320C2810, TMS320C2811, TMS320C2812
SPRS174T –APRIL 2001–REVISED MAY 2012 www.ti.com
Table 3-8. Peripheral Frame 2 Registers
(1)
NAME ADDRESS RANGE SIZE (x16) ACCESS TYPE
Reserved 0x00 7000 – 0x00 700F 16
System Control Registers 0x00 7010 – 0x00 702F 32 EALLOW Protected
Reserved 0x00 7030 – 0x00 703F 16
SPI-A Registers 0x00 7040 – 0x00 704F 16 Not EALLOW Protected
SCI-A Registers 0x00 7050 – 0x00 705F 16 Not EALLOW Protected
Reserved 0x00 7060 – 0x00 706F 16
External Interrupt Registers 0x00 7070 – 0x00 707F 16 Not EALLOW Protected
Reserved 0x00 7080 – 0x00 70BF 64
GPIO Mux Registers 0x00 70C0 – 0x00 70DF 32 EALLOW Protected
GPIO Data Registers 0x00 70E0 – 0x00 70FF 32 Not EALLOW Protected
ADC Registers 0x00 7100 – 0x00 711F 32 Not EALLOW Protected
Reserved 0x00 7120 – 0x00 73FF 736
EV-A Registers 0x00 7400 – 0x00 743F 64 Not EALLOW Protected
Reserved 0x00 7440 – 0x00 74FF 192
EV-B Registers 0x00 7500 – 0x00 753F 64 Not EALLOW Protected
Reserved 0x00 7540 – 0x00 774F 528
SCI-B Registers 0x00 7750 – 0x00 775F 16 Not EALLOW Protected
Reserved 0x00 7760 – 0x00 77FF 160
McBSP Registers 0x00 7800 – 0x00 783F 64 Not EALLOW Protected
Reserved 0x00 7840 – 0x00 7FFF 1984
(1) Peripheral Frame 2 only allows 16-bit accesses. All 32-bit accesses are ignored (invalid data may be returned or written).
40 Functional Overview Copyright © 2001–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320F2810 TMS320F2811 TMS320F2812 TMS320C2810 TMS320C2811 TMS320C2812
