TMS320F2810, TMS320F2811, TMS320F2812
TMS320C2810, TMS320C2811, TMS320C2812
SPRS174T –APRIL 2001–REVISED MAY 2012
www.ti.com
The following documents are available on the TI website (http://www.ti.com):
SPRU430 TMS320C28x CPU and Instruction Set Reference Guide describes the central processing
unit (CPU) and the assembly language instructions of the TMS320C28x™ fixed-point digital
signal processors (DSPs). It also describes emulation features available on these DSPs.
SPRU060 TMS320x281x DSP Analog-to-Digital Converter (ADC) Reference Guide describes the
ADC module. The module is a 12-bit pipelined ADC. The analog circuits of this converter,
referred to as the core in this document, include the front-end analog multiplexers (MUXs),
sample-and-hold (S/H) circuits, the conversion core, voltage regulators, and other analog
supporting circuits. Digital circuits, referred to as the wrapper in this document, include
programmable conversion sequencer, result registers, interface to analog circuits, interface
to device peripheral bus, and interface to other on-chip modules.
SPRU095 TMS320x281x DSP Boot ROM Reference Guide describes the purpose and features of the
bootloader (factory-programmed boot-loading software). It also describes other contents of
the device on-chip boot ROM and identifies where all of the information is located within that
memory.
SPRU065 TMS320x281x DSP Event Manager (EV) Reference Guide describes the EV modules that
provide a broad range of functions and features that are particularly useful in motion control
and motor control applications. The EV modules include general-purpose (GP) timers, full-
compare/PWM units, capture units, and quadrature-encoder pulse (QEP) circuits.
SPRU067 TMS320x281x DSP External Interface (XINTF) Reference Guide describes the external
interface (XINTF) of the 281x digital signal processors (DSPs).
SPRU061 TMS320x281x DSP Multichannel Buffered Serial Port (McBSP) Reference Guide
describes the McBSP available on the 281x devices. The McBSPs allow direct interface
between a DSP and other devices in a system.
SPRU078 TMS320x281x DSP System Control and Interrupts Reference Guide describes the
various interrupts and system control features of the 281x digital signal processors (DSPs).
SPRU074 TMS320x281x Enhanced Controller Area Network (eCAN) Reference Guide describes
the eCAN that uses established protocol to communicate serially with other controllers in
electrically noisy environments. With 32 fully configurable mailboxes and time-stamping
feature, the eCAN module provides a versatile and robust serial communication interface.
The eCAN module implemented in the C28x DSP is compatible with the CAN 2.0B standard
(active).
SPRU566 TMS320x28xx, 28xxx DSP Peripheral Reference Guide describes the peripheral reference
guides of the 28x digital signal processors (DSPs).
SPRU051 TMS320x281x Serial Communications Interface (SCI) Reference Guide describes the
SCI that is a two-wire asynchronous serial port, commonly known as a UART. The SCI
modules support digital communications between the CPU and other asynchronous
peripherals that use the standard non-return-to-zero (NRZ) format.
SPRU059 TMS320x281x Serial Peripheral Interface Reference Guide describes the SPI—a high-
speed synchronous serial input/output (I/O) port that allows a serial bit stream of
programmed length (one to sixteen bits) to be shifted into and out of the device at a
programmed bit-transfer rate. The SPI is used for communications between the DSP
controller and external peripherals or another controller.
88 Development Support Copyright © 2001–2012, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320F2810 TMS320F2811 TMS320F2812 TMS320C2810 TMS320C2811 TMS320C2812
