(1) The filter width is 6 VCLK4 cycles.
7.3.4 Enhanced Capture Module (eCAP) Electrical Data/Timing
Table 7-13. eCAPx Timing Requirements
TEST CONDITIONS MIN MAX UNIT
t
w(CAP)
Pulse width, capture input
Synchronous 2 t
c(VCLK4)
cycles
Synchronous with input filter 2 t
c(VCLK4)
+ filter width
(1)
Table 7-14. eCAPx Switching Characteristics
PARAMETER TEST CONDITIONS MIN MAX UNIT
t
w(APWM)
Pulse duration, APWMx output high or low 20 ns
