TMS570LS0714
SPNS226E –JUNE 2013–REVISED NOVEMBER 2016 www.ti.com
Submit Documentation Feedback
Product Folder Links: TMS570LS0714
Terminal Configuration and Functions Copyright © 2013–2016, Texas Instruments Incorporated
4.2.2 PZ Package Terminal Functions
4.2.2.1 High-End Timer (N2HET) Modules
Table 4-20. PZ Enhanced High-End Timer (N2HET) Modules
TERMINAL SIGNAL
TYPE
RESET
PULL
STATE
PULL TYPE DESCRIPTION
SIGNAL NAME 100 PZ
N2HET1[0]/ SPI4CLK / EPWM2B 19 I/O Pulldown Programmable,
20 µA
N2HET2 timer input capture or output
compare, or GIO.
Each terminal has a suppression filter with a
programmable duration.
Timer input capture or output compare. The N2HET
applicable terminals can be programmed as
general-purpose input/output (GIO).
N2HET1[2] / SPI4SIMO / EPWM3A 22
N2HET1[4] / EPWM4B 25
N2HET1[6] / SCIRX / EPWM5A 26
N2HET1[8] / MIBSPI1SIMO[1] 74
N2HET1[10] / nTZ3 83
N2HET1[12] 89
N2HET1[14] 90
N2HET1[16] / EPWM1SYNCI /
EPWM1SYNCO
97
MIBSPI1nCS[1] / N2HET1[17] / EQEP1S 93 Pullup
N2HET1[18] / EPWM6A 98 Pulldown
MIBSPI1nCS[2] / N2HET1[19] 27 Pullup
MIBSPI1nCS[3] / N2HET1[21] 39
N2HET1[22] 11 Pulldown
MIBSPI1nENA / N2HET1[23] / ECAP4 68 Pullup
N2HET1[24] / MIBSPI1nCS[5] 64 Pulldown
MIBSPI3nENA / MIBSPI3nCS[5] /
N2HET1[31] / EQEP1B
37 Pullup
GIOA[5] / INT[5] / EXTCLKIN
/EPWM1A/N2HET1_PIN_nDIS
10 Pulldown Disable selected PWM outputs
GIOA[2] / INT[2] / N2HET2[0] / EQEP2I 5 Pulldown
N2HET2 timer input capture or output
compare, or GIO.
Each terminal has a suppression filter with a
programmable duration.
Timer input capture or output compare. The N2HET
applicable terminals can be programmed as
general-purpose input/output (GIO).
GIOA[3] / INT[3] / N2HET2[2] 8
GIOA[6] / INT[6] / N2HET2[4] / EPWM1B 12
GIOA[7] / INT[7] / N2HET2[6] / EPWM2A 18
4.2.2.2 Enhanced Capture Modules (eCAP)
Table 4-21. PZ Enhanced Capture Modules (eCAP)
Terminal Signal
Type
Reset Pull
State
Pull Type Description
Signal Name 100
PZ
MIBSPI3SOMI[0] /
AWM1_EXT_ENA / ECAP2
34 I/O Pullup Fixed, 20 µA Enhanced Capture Module 2 I/O
MIBSPI3SIMO[0] /
AWM1_EXT_SEL[0] / ECAP3
35 Enhanced Capture Module 3 I/O
MIBSPI1NENA / N2HET1[23] /
ECAP4
68 Enhanced Capture Module 4 I/O
MIBSPI1NCS[0] /
MIBSPI1SOMI[1] / ECAP6
73 Enhanced Capture Module 6 I/O
