4.2.1.18 Supply for I/O Cells: 3.3V nominal
Table 4-18. PGE Supply for I/O Cells: 3.3V nominal
Terminal Signal
Type
Reset Pull
State
Pull Type Description
Signal Name 144
PGE
VCCIO 10 3.3-V
Power
– None Operating supply for I/Os
VCCIO 26
VCCIO 42
VCCIO 104
VCCIO 120
VCCIO 136
4.2.1.19 Ground Reference for All Supplies Except VCCAD
Table 4-19. PGE Ground Reference for All Supplies Except VCCAD
Terminal Signal
Type
Reset Pull
State
Pull Type Description
Signal Name 144
PGE
VSS 11 Ground – None Ground reference
VSS 21
VSS 27
VSS 28
VSS 43
VSS 44
VSS 47
VSS 50
VSS 56
VSS 88
VSS 102
VSS 103
VSS 115
VSS 121
VSS 122
VSS 135
VSS 138
VSS 144
