TMS570LS0714
SPNS226E –JUNE 2013–REVISED NOVEMBER 2016 www.ti.com
Submit Documentation Feedback
Product Folder Links: TMS570LS0714
Terminal Configuration and Functions Copyright © 2013–2016, Texas Instruments Incorporated
4.2.2.5 General-Purpose Input/Output (GIO)
Table 4-24. PZ General-Purpose Input/Output (GIO)
Terminal Signal
Type
Reset Pull
State
Pull Type Description
Signal Name 100
PZ
GIOA
GIOA[0] / INT[0] 1 I/O Pulldown Programmable,
20 µA
General-purpose input/output
All GPIO terminals are capable of generating
interrupts to the CPU on rising/falling/both edges.
GIOA[1] / INT[1] 2
GIOA[2] / INT[2] / N2HET2[0] /
EQEP2I
5
GIOA[3] / INT[3] / N2HET2[2] 8
GIOA[4]/ INT[4] 9
GIOA[5] / INT[5] / EXTCLKIN /
EPWM1A/ N2HET1_PIN_nDIS
10
GIOA[6] / INT[6] / N2HET2[4] /
EPWM1B
12
GIOA[7] / INT[7] / N2HET2[6] /
EPWM2A
18
GIOB
MIBSPI3nCS[0] / AD2EVT /
GIOB[2] /
EQEP1I/N2HET2_PIN_nDIS
38 I/O General-purpose input/output
4.2.2.6 Controller Area Network Interface Modules (DCAN1, DCAN2)
Table 4-25. PZ Controller Area Network Interface Modules (DCAN1, DCAN2)
Terminal Signal
Type
Reset Pull
State
Pull Type Description
Signal Name 100
PZ
DCAN1
CAN1RX 63 I/O Pullup Programmable,
20 µA
CAN1 Receive, or general-purpose I/O (GPIO)
CAN1TX 62 CAN1 Transmit, or GPIO
DCAN2
CAN2RX 92 I/O Pullup Programmable,
20 µA
CAN2 Receive, or GPIO
CAN2TX 91 CAN2 Transmit, or GPIO
