26
TMS570LS0714
SPNS226E –JUNE 2013–REVISED NOVEMBER 2016
www.ti.com
Submit Documentation Feedback
Product Folder Links: TMS570LS0714
Terminal Configuration and Functions Copyright © 2013–2016, Texas Instruments Incorporated
4.2.2.9 Local Interconnect Network Controller (LIN)
Table 4-28. PZ Local Interconnect Network Controller (LIN)
TERMINAL
SIGNAL
TYPE
RESET
PULL
STATE
PULL TYPE DESCRIPTION
SIGNAL NAME 100 PZ
LINRX 94 I/O Pullup Programmable, 20 µA LIN Receive, or GPIO
LINTX 95 LIN Transmit, or GPIO
4.2.2.10 Multibuffered Analog-to-Digital Converter (MibADC)
Table 4-29. PZ Multibuffered Analog-to-Digital Converter (MibADC)
Terminal Signal
Type
Reset Pull
State
Pull Type Description
Signal Name 100
PZ
MibADC1
AD1EVT 58 I/O Pulldown Programmable,
20 µA
ADC1 Event Trigger or GPIO
AD1IN[0] 42 Input – – Analog Inputs
AD1IN[1] 49
AD1IN[2] 51
AD1IN[3] 52
AD1IN[4] 54
AD1IN[5] 55
AD1IN[6] 56
AD1IN[7] 43
AD1IN[8]/AD2IN[8] 57
AD1IN[9]/AD2IN[9] 48
AD1IN[10]/AD2IN[10] 50
AD1IN[11]/AD2IN[11] 53
AD1IN[16]/AD2IN[0] 40
AD1IN[17]/AD2IN[1] 41
AD1IN[20]/AD2IN[4] 44
AD1IN[21]/AD2IN[5] 45
ADREFHI/VCCAD 46 Input/
Power
– – ADC High Reference Level/ADC Operating
Supply
ADREFLO/VSSAD 47 Input/
Ground
– – ADC Low Reference Level/ADC Supply Ground
MIBSPI3SOMI[0]/AWM1_EXT_
ENA/
ECAP2
34 AWM external analog mux enable
MIBSPI3SIMO[0]/AWM1_EXT_
SEL[0]/
ECAP3
35 AWM external analog mux select line 0
MIBSPI3CLK/AWM1_EXT_SEL
[1]/
EQEP1A
36 AWM external analog mux select line1
MibADC2
MIBSPI3nCS[0]/AD2EVT/GIOB[
2]/
EQEP1I/N2HET2_PIN_nDIS
38 I/O ADC2 Event Trigger or GPIO
To Next Page
