Thames Side Smart Series - Power; Environmental and Mechanical; Keyboard

Introduction
1-2
1.1.5 Power
Power supply 230 VAC ±10%, 50 Hz, 6 W máx.
Fuse 250 V, 100 mA slow fusion
Alimentation DC (optional for IP65) 7.5V … 15VDC, nominal 12V.
External fuse 500mA
1.1.6 Environmental and Mechanical
Operating temperature -10ºC a 40ºC
Storage temperature -25ºC a 70ºC
Size 282 x 158 x 71 mm (stainless steel version)
282 x 159 x 75.5 mm (ABS version)
Weight 1.85kg (stainless steel version)
1.1kg (ABS version)
Mounting Bench mount or bracket
1.2 Keyboard
The keyboard is on the front side of the equipment and has 6 keys.
These are the main functions of these keys:
Keys Normal status Setup
EXIT
Exit any operation Upwards
0
Zero the scale
To the left
(Cursor)
T
Enter stored tare
To the right
(Cursor)
Piece counting
Increase one digit
(Cursor)
Accumulation
Decrease one digit
(Cursor)
Print ticket Confirm a value
