Thames Side Smart Series - Digital Inputs; D_IN NUM (D_In No); Type(I) (Type)

Configuration and Calibration
3-20
3.8 Digital Inputs
(For application with Digital Inputs accessory)
Within the digital inputs configuration level, parameters showed in Figure 3.8.1 can be
found.
d
F
T
d
i
N
P
i
2
H
3
1
L
OFF
4
TARE CTARE 0ERO PRINT TOT CTOT
O
_
U
Y
_
n
C
E
nN
Figure 3.8.1 Digital Inputs
3.8.1 D_IN NUM (d_in no)
Number of digital input.
These are the options:
1, 2, 3, 4
3.8.2 TYPE(i) (type)
Input action.
These are the options:
OFF (off): Deactivated
TARE (tare): Tare
CLRTARE (ctare): Deactivate tare
ZERO (0ero): Zero
PRINT (print): Print
SUM (tot): Accumulation
CLRSUM (ctot): Deactivate accumulation
