Installation
4
-
3
4.3 Unit
Label
Next to the main disp
lay, the default units (kg) are s
ilkscreen printed. Adhesives with
different units are incl
uded.
Units: g, t, lb, oz, ton, N, kN
and an empty label.
Figure 4.3.1 Unit
Label
