Operation
2-5
Exit:
EXIT
When parameter d_loc
i
is on then the message loc (locked) will be shown and
blink three times.
2.10 Communications
This equipment has one serial communication port:
Port Rx/Tx: transmission and reception serial port
The communication channel can be configured from the Configuration Menu (see 3.4).
A second transmission channel is available as an optional extra.
The performance of the second communication channel can be configured from the
Configuration Menu (see 3.5).
2.10.1 General Characteristics of the Remote Controller
2.10.1.1 Remote Controller Commands
The equipment can be controlled through the Rx/Tx port. To carry out this function
the indicator must be configured in ‘DEMAND’ mode (see 3.4.1).
Operation Commands:
A Query/Set weight in F4 format
G Equivalent to EXIT + TARE keys
P Query/Set weight with response according to the selected format (see 3.4.3)
Q Equivalent to PRINT key
R Reset system
T Equivalent to TARE key
Z Equivalent to ZERO key
S Equivalent to Σ key
E Equivalent to EXIT + Σ keys
$ Weight query/set: The command does not require <CR>
STX, ENQ, ETX Weight query: the command does not require <CR>
SYN Weight query: the command does not require <CR>
SETPOINTS Programming: It allows to change the VL(i) parameter from the i digital output
(see 3.7.2).
The decimal point is taken from the system.
In case of TYPE(i) = ±REL o ±%REL: VL(i) = pppppp/100 %.
Program: S P i ± p p p p p p p
Consult: S P i ?
It returns the value in the programmed format.
Data transfer in ASCII format:
± : Sign: + positive value; - negative value
i : Digital output number (1 - 4)
