Operation
2-6
p : Weight (7 digits)
REMOTE Mode: It allows changing the i digital output, provided that
this is programmed TYPE(i) = REM (see 3.7.3)
Act: X O i x
Consult: X O ?
Answer: X O x
8
X
7
X
6
X
5
X
4
X
3
X
2
X
1
Data transfer in ASCII format:
i : Digital output number (1 - 4)
x
n
: Status of the digital output (n): 0 = OFF; 1 = ON
Read digital inputs: It allows reading the status of the digital inputs
Consult: X I ?
Answer: X I x
8
X
7
X
6
X
5
X
4
X
3
X
2
X
1
Data transfer in ASCII format:
x
n
: Status of the digital input (n): 0 = Low; 1 = High
Consult the number of weighings accumulated:
Command: SN
Answer: number of weighings
space + 7 digit ASCII ('0 '... '9')
Consult the total weight accumulated;
Command: ST
Answer: Total weight accumulated
sign + 7 digits ASCII ('0 '... '9') without decimal point
‘ ‘ N N
N N N N N
+ P P P P P P P
