Operation
2-7
2.10.1.2 Data Format
F1 Format:
<STX> POL ppppppp U G/N S T
F2 Format:
‘’ POL nnnnnnn T
F3 Format:
<STX> ‘1’ ‘ ‘ ‘0’ ‘ ’ POL nnnnnnn <ETX> T
F4 Format:
POL aaaaaaa T
F5 Format:
<STX> ‘ ’ POL nnnnnnn <ETX> T
F6 Format:
For UTILCELL remote display. The content of the display is transmited in
hexadecimal.
D7 D6 D5 D4 D3 D2 D1 Status T
Digit code:
bit 7: segment DP
bit 6: segment A
bit 5: segment B
bit 4: segment C
bit 3: segment D
bit 2: segment E
bit 1: segment F
bit 0: segment G
Status code:
bit 7: accumulation activated
bit 6: range 1 (R1)
bit 5: range 2 (R2)
bit 4: piece counting activated
bit 3: preset tare (PT)
bit 2: ZERO
bit 1: NET
bit 0: STABLE
Format F7:
<STX> status POL ppppppp T
The status is obtained when you add to 0x20
hex
the values of the lighted status LEDs:
Gross= 0x01
hex
Zero= 0x08
hex
Net= 0x02
hex
Standstill=0x20
hex
A
B
C
D
E
F
G
DP
