THERA-Trainer BEMO - Technical data

EN User manual THERA-Trainer bemo
13
Article no. A007-661_Rev 2.0 - Last edited: 2020-06-02
SYSTEM
8. Technical data
THERA-Trainer
Dimensions
l x w x h
89 cm x 143 cm x 118 – 158 cm
Floor space: approx. 1.3 m²
Weight
approx. 86.5 kg
Bed/couch width
up to 115 cm
Radius of movement:
‒ Position 1
‒ Position 2
55 mm
85 mm
Number of rotations range – passive training
1 – 100 rpm
Number of rotations range – active training
1 – 120 rpm
Torque range
‒ leg exerciser
‒ upper body exerciser
up to 15 Nm
up to 8 Nm
Continuous power braking force (active training)
100 Watt
Continuous power drive power (passive training)
100 Watt
Power consumption
125 – 135 Watt
Power supply
100 – 240 V~, 50/60 Hz
Mains fuse
250 V T 3.15 A HB (high break)
Medical device class
IIa
Protection class
II
Degree of protection
Type BF medica device
Sound emission
< 35 dB during active/passive training
Ambient conditions for use
5 °C to 40 °C
15% to 90% Rh
700 to 1060 hPa
Ambient conditions for transport/delivery
-25 °C to 70 °C
15% to 93% Rh
700 to 1060 hPa
Suitable for patients with
‒ Body height
‒ Body weight
120 cm to 200 cm
up to 180 kg
Materials used
Steel, aluminium, copper, plastic (PC/ABS, PMMA, PA6,
PA, PE, polyurethane, ROYALPLAST)
Service life
10 years
Stand-by mode power consumption
approx. 10 Watt
Software version
Control and display unit 2.7" wireless:
‒ Software 01.00.x
 User manual valid as of software version indicated
above
Dimensions of control and display unit
Diagonal: 6.8 cm
Width: 5.4 cm
Height: 4.0 cm
Flammability
Housing (cladding) enclosing electrical components
are made of non-combustible materials (metal)
or materials with fire protection class UL94-V0.
