18. Training
18.1. Control and display unit
18.1.1. Overview
(1) Training parameters display
(2) Lift column height buttons
(3) Emergency stop button
(4) Easy entry button
(5) Training time buttons
(6) Exercising resistance buttons
(7) Number of revolutions buttons
(8) STOP button
(9) START button
(10) Spasm detection button
(11) Direction of rotation button
18.1.2. Operation
Lift column height buttons:
WARNING!
Risk of injury due to insufficient distances!
 When adjusting the height of the lifting column, make sure that no parts of the body are pinched or squeezed.
The detection zone of the distance sensor is subject to a tolerance of +- 3 cm.
Surface (bed, body parts, etc.)
Drive unit
Front distance sensor
Detection zone 2 (3 cm)
Detection zone 1 (14 cm)
Infrared distance sensor
