EN User manual THERA-Trainer bemo
3
Article no. A007-661_Rev 2.0 - Last edited: 2020-06-02
OVERVIEW
(1) Double steering castor
(2) Frame
(3) Parking brake
(4) Electronic lifting column
(5) Mounting hook
(6) Status light
(7) Crossbeam
(8) Foot rest
(9) Drive unit
(10) Crank disc
(11) Patient emergency stop connection point
(12) Control and display unit bemo 2.7" wireless
(13) Front distance sensor
(14) Impact protection
The models of the THERA-Trainer have different features. This does not change the mode of operation
of movement training. The contents of this user manual (such as safety instructions, foreseeable misuse,
intended purpose, etc.) are valid for all models of the type THERA-Trainer bemo.
6 7
8
9
10 8
6
11
12
13
4
3
14
1
5
5
4
3
2
1
