User manual THERA-Trainer bemo EN
18
Article no. A007-661_Rev 2.0 - Last edited: 2020-06-02
Positioning of control and display unit:
Hook control and display unit into mounting hook 1.
‒ Mounting options on lifting column or crossbeam.
Make sure that the spiral cable does not get into foot rests or upper body exerciser accessories during
training.
10.2.6. Power cable
Damage due to incorrect installation!
Make sure that plug is plugged in the socket correctly when connecting cable.
Note position of plug.
Only use the power cable supplied by the manufacturer.
Connect plug 1 to socket 2.
Connect power plug 3 to socket.
10.2.7. Potential equalisation
Danger to life due to electric shock!
Only exercise with the equipotential bonding cable connected if the patient is connected to other medical
devices during training.
If the trainer is used in room classes 2 (operating theatres, intensive care units, cardiac catheter rooms
in accordance with DIN VDE 0100 part 710) as a medical device, risks to patients, doctors/therapists
and third parties as a result of different voltage potential must be avoided. Connect trainer by plugging
a connected equipotential bonding cable of the room into the trainer connection.
