Thermo King RD-MT - Remote Evaporator Specifications; Refrigeration System; Electrical

To Next Page

To Previous Page

147

Remote Evaporator Specifications

Refrigeration System

Evaporator Coil Type Direct Expansion

Refrigerant Type R404a

Heat/Defrost Method Hot Gas

Electrical

Control System Voltage 12.5 Vdc

Spectrum Evaporator Fan Motor: Horsepower 0.13 hp

Fan Voltage 8 to 16 Vdc

RPM 1900

Full Load Amps 8.7 amps per motor

Fuse F1-1, F1-2, F2-1, F2-2 30 amp

Remote Liquid Line Solenoid (15 watt):

Current Draw 1.2 amps

Resistance 10.4 ohms

Remote Hot Gas Solenoid (18 watt):

Current Draw 1.44 amps

Resistance 8.68 ohms

Remote Suction Line Solenoid (18watt):

Current Draw 1.44 amps

Resistance 8.68 ohms
