Time Electronics User Manual
5051 Plus and 7051 Plus Multifunction Calibrators v2.1
xx51+ Multifunction Calibrators Page 39 of 64
7.8.2. Thermocouple Simulation
There are eight types of thermocouple that may be simulated, each selected from the Temperature
function selection screen.
The range of temperatures that can be simulated depends on the type of thermocouple selected:
B 0ºC to 1820ºC
E -270ºC to 1000ºC
J -210ºC to 1200ºC
K -270ºC to 1372ºC
N -270ºC to 1300ºC
R -50ºC to 1768ºC
S -50ºC to 1768ºC
T -270ºC to 400ºC
Thermocouple
