7.11.2. Selecting Range
The ranges available depend on the function selected. The ranges available are:
Function Ranges
DC Volts 100mV, 10mV, 1V, 10V, 100V, 1kV
AC Volts
100mV, 10mV, 1V, 10V, 100V, 1kV
DC Current 10mA, 100mA, 1A, 3A
AC Current 1A, 3A
Resistance 100R, 1kR, 10kR, 100kR, 1MR, 10MR, 100MR
Frequency 10Hz, 100Hz, 1kHz, 10kHz, 100kHz, 1MHz
Period 5ms to 3us
Thermocouples K, E, J, N, R, S & T
PT100 4 wire. -240°C to 850°C
To change range, click on the drop down arrow button adjacent to range window. The available
ranges will be shown in a list and the desired range can be selected.
7.11.3. Selecting Display Resolution
The xx51 Multimeter is able to display its readout at three resolutions:
• 4.5 digits
• 5.5 digits
• 6.5 digits
By default, it will display using 6.5 digits.
The selected resolution is indicated by the highlighted button in the area labelled “Digits” (e.g. in the
screen picture above, 6.5 digits are selected).
To change the number of digits displayed, click on the required button.
Note: The maximum number of digits is restricted for some functions and ranges by the accuracy and
stability specification of the xx51.
