3-74
Chapter 3 INSTALLATION AND SETTING PROCEDURES (HARDWARE)
To make longer cable lengths than those shown in the above table, use over 4-pair shielded CPEV cable. (For
the cable connection, see p. 3-70.)
The relationship of the CPEV cable conductor diameter to the maximum cable distance is as follows:
[RM-300X]
No. of extension
units
Cable
RM-300X alone
RM-300X +
RM-210F x 1
RM-300X +
RM-210F x 2
RM-300X +
RM-210F x 3
ø0.65 mm 586 m 440 m 352 m 293 m
ø0.9 mm 1141 m 856 m 684 m 570 m
ø1.2 mm 1200 m 1200 m 1200 m 1010 m
No. of extension
units
Cable
RM-300X +
RM-210F x 4
RM-300X +
RM-210F x 5
RM-300X +
RM-210F x 6
RM-300X +
RM-210F x 7
ø0.65 mm 251 m 220 m 195 m 176 m
ø0.9 mm 489 m 428 m 380 m 342 m
ø1.2 mm 865 m 757 m 673 m 606 m
[RM-500]
Unit
Cable
RM-500 x 1 RM-500 x 2 RM-500 x 3 RM-500 x 4
ø0.65 mm 1083 m 541 m 361 m 270 m
ø0.9 mm 1200 m 1053 m 702 m 526 m
ø1.2 mm 1200 m 1200 m 1200 m 932 m
• When the VX-3000DS or the VX-3150DS is operating on AC power
The maximum distance of power cable between the RM-300X or RM-500 and the VX-3000DS or the VX-
3150DS is as follows.
The following table shows the maximum cable distance when STP Category 5 straight cable (with RJ45
connectors) is used.
[RM-300X]
No. of extension
units
Cable
RM-300X alone
RM-300X +
RM-210F x 1
RM-300X +
RM-210F x 2
RM-300X +
RM-210F x 3
STP Category 5 355 m 266 m 213 m 177 m
No. of extension
units
Cable
RM-300X +
RM-210F x 4
RM-300X +
RM-210F x 5
RM-300X +
RM-210F x 6
RM-300X +
RM-210F x 7
STP Category 5 152 m 133 m 118 m 106 m
[RM-500]
Unit
Cable
RM-500 x 1 RM-500 x 2 RM-500 x 3 RM-500 x 4
STP Category 5 656 m 328 m 218 m 164 m
