TOHATSU EverRun MX 18E2 Service Manual

5-14
Power Unit
2st X18E2 2012
GB







































49/57












































518
LT
518
GREASE
OBMOBM
OBM
GREASE
OBMOBM
OBM
GREASE
OBMOBM
OBM
LIT
GREASE
LIT
LIT
GREASE
LIT
5910
LT
5910
1
     
2
     
     
1
     
2
     
1
     
2
     
1
     
2
     
     
TB
1342
1342
2st OIL
2st
OIL
Cylinder & Crank Case P/L Fig. 1
Ref.
No.
Description Remarks
Q'ty
Ref.
No.
Description Remarks
Q'ty
1 Cyl Block & Crankcase Assy 1
2 Nipple 4.8-5 1
3 Nipple 5.5-5 1
4 Nipple L 1
5 Bolt 10 M8 L=45mm
6Washer 10 M8
7 Dowel Pin 6-12 2
8 Cylinder Head Assy 1
9 Welch Plug 1
10 Cylinder Head Gasket 1
11 Cylinder Head Bolt 10
12 Washer 10 M8
13 Thermostat 1 Mark 52C PRV
14 Thermostat Cap 1
15 Thermostat Cap Gasket 1
16 Bolt 2 M6 L=30mm
17 Anode 1
18 Bolt 2 M6 L=16mm
19 Exhaust Cover Assy 1
20 Bolt 1 M8 L=8mm
21 Gasket 8.1-15-1 1
22 Exhaust Cover (Inner) 1
23 Exhaust Cover Gasket 1
24 Exhaust Cover Gasket 1
25 Bolt 11 M6 L=25mm
26 Washer 11 M6
27 Hose 1 L=30mm
28 Hose 1 L=220mm
29 Check Valve 1
30 Clip 1 ø8
31 Clip 1 ø7
32 Clip 2 ø7
Do not reuse.
Do not reuse.
Do not reuse.
Do not reuse.
2st
OIL
2st OIL
518518
LT
518
LIT
GREASE
LIT
5185910
LT
5910
TB
13421342
1342
GREASE
OBMOBM
OBM
MX18EFSch05a120622.qxd12.6.22 2:39 PMページ14
