TOHATSU EverRun MX 18E2 Service Manual

Bracket
7-18
2st X18E2 2012
GB





















 

GREASE
OBMOBM
OBM
GREASE
OBMOBMOBM
OBM
GREASE
OBMOBMOBM
OBM
GREASE
OBMOBMOBM
OBM
GREASE
OBMOBM
OBM
P/L Fig. 13
Shift
1 Shift Lever 1
2 Wave Washer D=12 1 M12
3 Oil Seal 14-20-4.5 1
4 Shift Lever Stopper 1
5 Bolt 1 M6 L=12mm
6Washer 1 M6
7 Shift Lever Stop Adjust 1
8 Split Pin 2.5-22 1
9 Shift Lever Stopper 1
10 Bolt 1 M6 L=16mm
11 Spring Washer 1 M6
Ref.
No.
Description Remarks
Q’ty
12 Bushing 2
13 Shift Rod (S) 1 for Transom “S”
13 Shift Rod (L) 1 for Transom “L”&“UL”
14 Shift Rod Joint 1
15 Spring Pin 3-12 2
16 Shift Rod Lever 1
17 Split Pin 2.5-20 1
18 Pin 1
19 Split Pin 1.6-10 1
20 Drain Plug (Engine Basement) 1
Ref.
No.
Description Remarks
Q’ty
GREASE
OBMOBM
OBM
Do not reuse.
Do not reuse.
MX18EFSch07120622.qxd12.6.223:28PM  ページ18
