6-32
Lower Unit
2st X18E2 2012
GB
8
w
0q
9
2
3
aa
4
1
4
5
1
G
G
‘‘G’’
q
2
1 Roller Bearing
Do not reuse.
24) Inspection of Pinion (B) Gear and
Forward (A) Gear
1. Check pinion (B) gear and forward (A) gear teeth and clutch
claws for crack, damage and wear. Replace if necessary.
Bevel Gear Bearing Install Tool 1 :
P/N. 346-72719-0
25) Assembly of Forward (A) Gear
1. Use a press to install new ball bearing to forward (A) gear.
26) Disassembly of Gear Case
1. Remove roller bearing 1 by using the following tools.
When installing guide
2
and flange
w
, face
“G” mark forward direction.
Roller Bearing Press Kit :
P/N. 3AC-72900-1
Bearing Outer Press Guide 2
Roller Bearing Press Rod 3
Roller Bearing Press 4
O ring5
Roller Bearing Press Collar 8
Roller Bearing Press Bolt 9
Bolt 0
Washer q
Roller Bearing Press Flange w
MX18EFSch06120622.qxd12.6.222:43PM ページ32
