TOHATSU EverRun MX 18E2 Service Manual

8-6
Electrical System
2st X18E2 2012
GB
P/L Fig. 6










 






























LIT
GREASE
LIT
BT
1373N1373N
1373N
SOC
OIL-COMP.
GM
SOCSOC
LIT
GREASE
LIT
2st OIL
2st
OIL
     
     
21 Clamp 6.5-47.5p 1
22 Screw 1 M5 L=10mm
23 Throttle Cam 1
24 Bolt 2 M5 L=14mm
25 Lead Wire Band 1
26 CD Unit 1
27 CD Unit Bracket 1
28 Bolt 1
29 Washer 6-16-1.5 1
30 Ignition Coil Assy W/Label 1
Ref.
No.
Description Remarks
Q'ty
31 Plug Cap 2
32 Plug Cap Terminal 2
33 Band 104 2
34 Caution Decal (B)
35 Bolt 2 M6 L=30mm
36 Washer 2 M6
Ref.
No.
Description Remarks
Q'ty
OIL-COMP.
GM
SOCSOC
SOC
2st
OIL
2st OIL
BT
1373N1373N
1373N
LIT
GREASE
LIT
