12. MEASUREMENT WITH AUTO TRACKING
73

• When "Tracking" is selected in "Trach Setting" in the "Configuration" tab of <Motor configuration>,
the function of the following softkeys will change depending on the option selected in "Srch method"
and Auto Tracking will be added.
Motor settings: "11.1 Auto Pointing Settings", "Forecast time" and "Wait time" operation:
"12.1 Auto Tracking Settings"
"Motor"
setting
Softkey
When "Track" set in "Search Setting"
When "None" set in
"Search Setting"
"Srch method" is R.C.
"Srch method" is G.S.
(Global Search)
[SRCH] Performs Auto Pointing then Auto Tracking Performs Auto Pointing
[MEAS]
Performs Turning
operation then distance
measurement/Auto
Tracking
Performs Auto Pointing
then distance
measurement/Auto
Tracking
Performs angle and
distance measurement
[RC]
Rotates directly in the direction of the Remote
Controller then performs Auto Pointing
Rotates in the direction
specified by the Remote
Controller then performs
Auto Pointing
Auto Tracking
Obstacle
Tar ge t
Target found
"Prism wait"
Target found
not found
Auto Tracking continues in predicted
direction
"Target lost"
Re-search
Target found
Tar ge t
not found
Sighting terminates (Auto Tracking idle)
Tar ge t
not found
Target found
Tar ge t
not found
