External GPS Antenna Connector
The external GPS antenna connector allows an optional external
antenna to be connected to the controller for post-process survey
applications.
Figure 1-8. GMS-2 External GPS Antenna Connector
System Cables
The GMS-2 package includes standard communication and power
cables for communicating with the GMS-2 and providing a power
source. Table 1-1 lists the cables included in the standard GMS-2
package.
Table 1-1. GMS-2 Package Cables
Cable Description Cable Illustration
AC Power cable and
adapter
Connects the GMS-2 to a
grounded outlet.
Cable p/n 22-060002-01
Adapter p/n 22-060001-01
USB cable
Connects the GMS-2 to an
external device (controller
or computer) for high-speed
data transfer and receiver
configuration.
p/n 14-008081-01
External GPS
Antenna
Connector
